The Micronic 24-2 Rack is offered to store 3.50ml tissue tubes with Screw Caps. The 24-2 Rack is standard available with laser-etched 1D barcode on the A1-H1 side of the rack. Micronic also offers the service to supply unique laser-etched 1D barcodes in customized formats on any side of the rack.
Micronic labware is manufactured and assembled in-house in a NEN-EN-ISO14644-1 Class 7 certified clean room environment (which is comparable to the US Federal Standard 209E Class 10,000).
For the manufacturing of its long term sample storage labware products Micronic uses solely virgin plastic raw material. The raw materials and auxiliary agents are selected based on the specifications that satisfy the high quality requirements of our products. The materials are FDA approved and comply with the (USA) USP XXII tests, including class VI (Medical approved), and the European Pharmacopoeia-monograph 3.2.2 unless communicated otherwise. Material components used to produce Micronic labware can be traced via the lot number indicated on the packaging.
The materials used for Micronic tubes are the result of extensive research. One selection criterion is that the amount of measurable extractables leaching into samples is minimized.
By maintaining the highest possible hygiene level during our production processes, Micronic manufactured labware is free of any detectable RNase or DNase contamination and the endotoxin level of produced and packaged labware is limited to an acceptable minimum (< 0.01 EU/ml). Our products are periodically tested on RNase, DNase and their endotoxin levels by independent expert organizations.
The Micronic 2D Data-Matrix codes and 1D barcodes are produced conform industry standards. The 2D Data-Matrix code (which adheres to the ECC200 standard) and 1D barcode (type 128B) are laser-etched into the code area and are guaranteed unique.
Products produced by Micronic are tested according to AQL inspection level G2 and AQL value 0.4.
Micronic Sample Storage tubes are classified as general laboratory products according to leading European Life Science Organizations (GAMBICA, FHI, LABMAS, Laborama, SPECTARIS). More information can be found here.
Upon request, Micronic products can be supplied gamma irradiated or ethylene oxide treated.
Our products comply with the IATA requirements for the transport of diagnostic specimens (UN packing instruction 602 and 650), assuming that our products are properly used (closed).
If you have any additional questions on the quality and safety of our products, please feel free to contact Micronic at sales@micronic.com.
Drawing upon over 35 years of experience in manufacturing and supplying traceable sample storage solutions to research centers and laboratory facilities, Micronic has developed a Next Generation Ultra- Low Temperature Tube Storage Rack Range. The Micronic Ultra-Low Temperature (ULT) Racks do not simply have a nicer design – they are better in every way. The racks have many unique features including its extremely strong design for cryogenic storage, a novel “icebreaker” cover lock mechanism, cover prints indicating rack and tube type, rack orientation marks and a highly transparent cover which enables easy visual checking of the enclosed samples.
Precision manufactured in a certified Class 7 clean room production facility, the Micronic ULT Racks are based on the Society for Laboratory Automation and Screening (ANSI/SLAS) standards for storage racks and accommodate 96, 48 or 24 tubes. Absolute traceability and reproducibility on the racks is ensured through novel laser-etched alphanumeric visual location aids on top of the racks and a unique laser-etched 1D barcode on the side of the racks. The open bottom design of the storage racks facilitate quick defrosting of samples.
| Parameter | Micronic 24-2 Rack |
|---|---|
| Material | Highest Purity PC |
| Rack height | 19.0mm |
| Height with cover | 37.8mm |
| Rack length | 127.8mm |
| Rack width | 85.5mm |
| Chemical resistance | ++/+ |
| Temperature range | Vapor phase LN2 to +140ºC |
| Article Number | Description | Unit Size | Case Size |
|---|---|---|---|
| MP51409 | Micronic 24-2 Rack with high cover for tubes capped with Screw Caps (barcoded A1-D1 side) | 10 racks | 4 |
| Article Number | Description | Unit Size | Case Size |
|---|---|---|---|
| MP52906 | 3.50ml 2D Data-Matrix coded Screw Cap tubes with External Thread Flat bottom in Micronic 24-2 Rack with high cover (Barcoded A1-D1 side) | 10 racks | 4 |
| MP52906-Y20 | 3.50ml 2D Data-Matrix coded Screw Cap tubes with External Thread Flat bottom precapped with Grey Screw Cap Bulk in Micronic 24-2 Rack with high cover (Barcoded A1-D1 side) | 10 racks | 4 |
A wide opening enables easy loading and removal of tissue samples. In addition to storage, the tubes can also be used for secure transportation. Working volume (+21°C): 3.35ml with Screw Cap.
Micronic Screw Caps for internally threaded tubes securely seal tubes for long-term sample storage at ultra-low temperatures.
The Micronic Rack Reader DR505 features a passive anti-frost system, which enables users to read racks filled with 2D codes tubes straight from the freezer.
The Micronic Screw Cap Recapper CS100 line is developed to improve the manual (de)capping of tubes because they are set to a precise torque value.
