6.00ml Tubes External Thread Hybrid
The 6.00ml tubes with external thread hybrid guarantee absolute sample traceability with 4 coding concepts and optimize working volume (6.00ml at +21°C with Screw Cap).
Find your ideal sample storage tube with our new Tube Configurator
Sample Storage Racks
Micronic 24-4 Rack
The Micronic 24-4 Rack can hold 24 individual 6.00ml (Hybrid) tubes with Screw Caps. Racks made from Polycarbonate have excellent properties for low temperature conditions which make them ideal for long term use in automated cryogenic storage facilities. The material used to manufacture the racks is selected on quality and the highest purity levels. The racks have an extremely strong design which minimizes deformation due to temperature changes.
Our Standards
Product Quality Information
Micronic operates corporate integrated Quality Management System (QMS) that is certified to ISO 9001:2015.
Reducing our impact on the environment is an integral part of our continuous improvement efforts. The environmental policy of Micronic is determined by our headquarters in the Netherlands, which is certified to ISO 14001:2015.
Certified Class 7 clean room
Micronic labware is manufactured and assembled in-house in a NEN-EN-ISO14644-1 Class 7 certified clean room environment (which is comparable to the US Federal Standard 209E Class 10,000).
Virgin material and approvals
For the manufacturing of its long term sample storage labware products Micronic uses solely virgin plastic raw material. The raw materials and auxiliary agents are selected based on the specifications that satisfy the high quality requirements of our products. The materials are FDA approved and comply with the (USA) USP XXII tests, including class VI (Medical approved), and the European Pharmacopoeia-monograph 3.2.2 unless communicated otherwise. Material components used to produce Micronic labware can be traced via the lot number indicated on the packaging.
Extractables
The materials used for Micronic tubes are the result of extensive research. One selection criteria is that no measurable amount of extractables should leach into samples.
RNase, DNase and endotoxin (pyrogen)
By maintaining the highest possible hygiene level during our production processes, Micronic manufactured labware is free of any detectable RNase or DNase contamination and the endotoxin level of produced and packaged labware is limited to an acceptable minimum (< 0.01 EU/ml). Our products are periodically tested on RNase, DNase and their endotoxin levels by independent expert organizations.
Laser-etched codes
The Micronic 2D Data-Matrix codes and 1D barcodes are produced conform industry standards. The 2D Data-Matrix code (which adheres to the ECC200 standard) and 1D barcode (type 128B) are laser-etched into the code area and are guaranteed unique.
Product quality control
Products produced by Micronic are tested according to AQL inspection level G2 and AQL value 0.4.
CE marking
Micronic Sample Storage tubes are classified as general laboratory products according to leading European Life Science Organizations (GAMBICA, FHI, LABMAS, Laborama, SPECTARIS). More information can be found here.
Sterilization
Upon request, Micronic products can be supplied gamma irradiated or ethylene oxide treated.
IATA
Our products comply with the IATA requirements for the transport of diagnostic specimens (UN packing instruction 602 and 650), assuming that our products are properly used (closed).
If you have any additional questions on the quality and safety of our products, please feel free to contact Micronic at sales@micronic.com.
Our solutions
A STATE-OF-THE-ART RACK RANGE
Drawing upon over 35 years of experience in manufacturing and supplying traceable sample storage solutions to research centers and laboratory facilities, Micronic has developed a Next Generation Ultra- Low Temperature Tube Storage Rack Range. The Micronic Ultra-Low Temperature (ULT) Racks do not simply have a nicer design – they are better in every way. The racks have many unique features including its extremely strong design for cryogenic storage, a novel “icebreaker” cover lock mechanism, cover prints indicating rack and tube type, rack orientation marks and a highly transparent cover which enables easy visual checking of the enclosed samples.
Precision manufactured in a certified Class 7 clean room production facility, the Micronic ULT Racks are based on the Society for Laboratory Automation and Screening (ANSI/SLAS) standards for storage racks and accommodate 96, 48 or 24 tubes. Absolute traceability and reproducibility on the racks is ensured through novel laser-etched alphanumeric visual location aids on top of the racks and a unique laser-etched 1D barcode on the side of the racks. The open bottom design of the storage racks facilitate quick defrosting of samples.
features & benefits
Micronic 24-4 Rack
Alphanumeric coding
Unique laser-etched Alphanumeric coding on top of the rack
ultra-low temperatures
Made from Polycarbonate which has excellent properties for low temperatures
"icebreaker" mechanism
Novel locking system for cryogenic storage: "icebreaker" mechanism
Compatibility
Compatible with the leading sample storage automation systems (-20°C, -80°C and lower temperatures)
RNASE/DNASE/PYROGENS
Free of any detectable RNase or DNase contamination and the endotoxin level of produced and packaged labware is limited to an acceptable minimum (< 0.01 EU/ml)
CLASS 7 CLEAN ROOM
Micronic labware is manufactured and assembled in-house in a NEN-EN-ISO14644-1 Class 7 certified clean room environment
Specifications
Product information
| Parameter | Micronic 24-4 Rack |
|---|---|
| Material | Highest Purity PC |
| Rack height | 30.0mm |
| Height with cover | 55.8mm |
| Rack length | 127.8mm |
| Rack width | 85.5mm |
| Chemical resistance | ++/+ |
| Temperature range | Vapor phase LN2 to +140ºC |
Testimonials
What our customers say
article numbers
Ordering information
Tube storage racks in 24-well format
| Article Number | Description | Unit Size | Case Size |
|---|---|---|---|
| MP51403 | Micronic 24-4 Rack with high cover for tubes capped with Screw Caps (barcoded A1-D1 side) | 10 racks | 2 |
6.00ml Screw Cap tubes with Internal Thread without Caps
| Article Number | Description | Unit Size | Case Size |
|---|---|---|---|
| MP52410 | 6.00ml 2D Data-Matrix coded Screw Cap tubes in Micronic 24-4 Rack with high cover (Barcoded A1-D1 side) | 10 racks | 2 |
6.00ml Screw Cap tubes with Internal Thread precapped with Screw Caps
| Article Number | Description | Unit Size | Case Size |
|---|---|---|---|
| MP52410-Z20 | 6.00ml 2D Data-Matrix coded Screw Cap tubes precapped with Grey Screw Cap in Micronic 24-4 Rack with high cover (Barcoded A1-D1 side) | 10 racks | 2 |
6.00ml Screw Cap Tubes with External Thread Hybrid Flat bottom without Caps
| Article Number | Description | Unit Size | Case Size |
|---|---|---|---|
| MP52966 | 6.00ml 2D Data-Matrix coded Screw Cap tubes with External Thread Hybrid W1D Flat bottom in Micronic 24-4 Rack with high cover (Barcoded A1-D1 side) | 10 racks | 2 |
| MP52967 | 6.00ml 2D Data-Matrix coded Screw Cap tubes with External Thread Hybrid W00 Flat bottom in Micronic 24-4 Rack with high cover (Barcoded A1-D1 side) | 10 racks | 2 |
